Parametric Modular Collectible Display Case, now with LED Back-Lighting. Wish I would had done it sooner, much better than in bags in a box out of site. Many others have made versions like this. Here it’s meant to be attached to a board and framed up, also using as little filament as possible. Most brick MINIFIGS fit in these smaller-width hexagons.

**2023 Dec. 3rd update, Vase Modules.

Multi Color / Part Christmas Tree Vase versions and additional parts for 2022. STL’s are on this site, Source Files (FreeCAD), and more parts will be posted on my personal website with just a click to download, no requirements/login to get files.

***2023/11/03 Updates, none for main frame, but many addons, more may come but out of filament. Documentation will be made soon…. So today just new pictures and modules..

**2022-12-05 Made some updates, larger parts with compression bolts to keep layers compressed.

Now that I’m painting again with shaking hands and unbalanced sitting and standing. I realized I needed an Easel that can…

• Have a fixed but easily moved bar over the painting that I can rest my hands on without touching the wet painting.

• Also need an Easel that could hold me up or support my weight when I lose balance or need support to stay up.

• A shelf under paintings for stuff.

• A flexible stand on the left for reference or tablets/screens. (Right now thinking of just using a monitor arm for this)

• On the right side 2 glass pallets, A long strip on top for raw out-of-the-tube paint with tubes stacked above 300mm x 100mm. Then below this a 2nd glass pallet for mixing and using 300mm x 300mm or larger.

• Hacking up 2 cool/warm adjustable LED lights to attach to the top of the frame with their adjustable arms. The one on the left has a magnifying lens with it so I can see details of the reference materials. The 2nd one will be over the mixing pallets.

• Adjustable angle for canvas mount, which can be vertical or facing up or down.

• Able to rotate painting as I’m painting to get different angles while painting, (upside down, on the side, etc..)

So its been since 1990’s that I touched Oil Paints. Tried some abstract paintings that confirmed what I knew, I’m a realistic artist, So I have been starting back up and working on Portraits.

Did some color studies 1^st, then some eyes, then my 1^st ever Oil Portrait. More on the way….

Miscellaneous 3D Prints and Source Files *updated Dec.3rd 2023.

Various source files for 3D printing. 3D prints that I have created that do not get a whole page on my site. Wide range of items will be included.

This Page will be updated over time as I add new ones.

Bricked 3D, the last printers you will need.

3D Printers that I designed.

Coming Soon!

3D Printable Terrain Maps that can also be CNC’ed. Most have elevations multiplied by 4.2 times to give height variations to view. Other wise they would just be a few layers thick total across whole map.

This Page will be updated over time as I add new maps.

Enjoy!

`mike

This is a total remake of my original versions. This time I made them in FreeCAD using a spreadsheet to control all aspects of the design for an easy and quick way to make changes.

A few years ago the area around my residents bloomed with all sorts
of mushrooms, then again in 2021.

Powered, Air-Purifying Respirator (PAPR) and More.

I have been working on these designs a few years ago and have plans for commercial plastic injection molded add-ons / that enable disposable and face respirators to be airtight. They require a scuba mouthpiece and nose clips.

Once installed ALL air goes through scuba mouthpiece and through air filters, NO leakage from side of masks or for people with beards (like myself and why I created these, so I do not have to shave my beard).

Due to COVID-19 I’m posting my 3D prototypes for personal use. With hopes of finding support and funds that I have no way to get myself.

I have been working on several different types of additive and subtractive systems. SO far only making them to the CAD designs.

Due to current world issues I’m just posting them to share.I would love to find funding to get these designs built and tested.
